Stainless Steel 309H Sheet and Plates

Victor Sheets and Plates stands out as a top manufacturer and supplier of Stainless Steel 309H Sheets and Plates in Abuja, Nigeria. They’re well-regarded for delivering high-quality stainless steel materials that are specifically designed to thrive in high-temperature and corrosive environments. Stainless Steel 309H is essentially a high-carbon variant of SS 309, which means it boasts improved strength and remarkable oxidation resistance when the heat is on. Victor Sheets and Plates is committed to ensuring that their products meet international quality standards, providing a superior surface finish, precise dimensions, and long-lasting durability. They cater to a variety of industries, including power generation, petrochemicals, furnace equipment, and heat treatment, offering reliable and high-performance stainless steel solutions.

SS 309H Chequered Plate

SS 309H Perforated Sheets

SS 309H Shim Sheet

ASTM A240 Stainless Steel 309H Sheets Dealer in Lagos, SS 309H Plates Supplier in Lagos, Stainless Steel S30909 Sheets and Plates in Port Harcourt, Stainless Steel 1.4833 Sheets and Plates Size Chart, 309H SS Sheets and Plates Price in Kano, ASME SA240 SS 309H Plates Supplier in Nigeria, 309H Stainless Steel Sheets in Ibadan, Stainless Steel 309H Sheet and Plate Supplier in Nigeria

The Stainless Steel 309H Sheets and Plates are made up of 22–24% chromium and 12–15% nickel, which gives them exceptional resistance to oxidation, scaling, and heat. The higher carbon content (up to 0.08%) boosts creep strength and structural stability when exposed to high temperatures. This alloy also contains trace amounts of manganese, silicon, and phosphorus to enhance its mechanical integrity. SS 309H has a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of 40%, with a density of 8.0 g/cm³ and a melting point ranging from 1395 to 1450°C, ensuring it performs excellently both thermally and mechanically.

Stainless Steel 309H Sheet and Plates Specification

Specifications	ASTM A240 / ASME SA240
Size	1/4″ to 4″
Range	5mm To 150mm
Thickness	4mm-100mm
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface	2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form	Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.

SS 309H Sheets and Plates Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Ni	Fe
SS 309	0.20	2	1	0.045	0.030	23	14	60
SS 309H	0.04-0.10	2.0	0.75	0.045	0.03	22.0-24.0	15.0	58.0-63.0

SS 309H Sheets and Plates Mechanical Properties

Grade	Tensile Strengtd ksi (min)	Yield Strength 0.2% ksi (min)	Elongation %	Hardness (Brinell) max
309/S	75	30	40	95
309/H	40	30	40	217

Equivalent Grades of A240 Stainless Steel 309H Sheets and Plates

STANDARD	WERKSTOFF NR.	UNS
SS 309H	1.4833	S30909

309H Stainless Steel Hot Rolled Sheets Price in Kano, Stainless Steel 309H Shim Sheets Weight Chart, SS 309H Perforated Sheets Supplier in Nigeria, Stockist of SUS 309H Sheets and Plates in Ibadan, 309H SS Cold Rolled Sheets Supplier in Nigeria, 309H SS Cold Drawn Plates Price List in Abuja, SS 309H Chequered Plates Supplier in Ibadan, Stainless Steel 309H Chequered Plates Exporter in Lagos, DIN 1.4833 Stainless Steel Plates Exporter in Nigeria, Stainless Steel Sheet 309H 2b Finish Exporter in Port Harcourt

If You Are Looking To Buy High Quality Piping Products ?

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Largest Stainless Steel 309H Sheet and Plates Manufacturer and Exporter in Abuja, Nigeria

Victor Sheets and Plates based in Abuja, Nigeria, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.

UNS S30909 Stainless Steel Sheets Distributor in Nigeria, SS 309H Plates Supplier in Abuja, Stainless Steel 309H Sheets Weight Chart, 309H Stainless Steel Hot Rolled Sheets Exporter in Ibadan, Stainless Steel 309H Shim Sheets Manufacturer in Lagos, SS 309H Chequered Plates Price List in Nigeria, 309H Stainless Steel Sheets Sizes in mm, Stainless Steel Sheet 309H 2b Finish Distributor in Port Harcourt, Stainless Steel 309H Sheets and Plates Exporter in Kano

Stainless steel 309H sheets and plates offer many advantages, including excellent resistance to high temperature oxidation and corrosion, making them ideal for harsh environments Due to the high carbon content they retain strength and staying power exist longer at high temperatures (up to 2000°F or 1093°C ). The material also boasts excellent resistance to heat fatigue, stress and cracking. Stainless steel 309H is highly weldable, ensuring ease of fabrication. It is also scratch resistant and can withstand acidic and basic environments. These properties make it suitable for industries such as aerospace, chemical processing and power generation.

Types of Stainless Steel 309H Sheet and Plates

BA Finish Stainless Steel 309H Plates in Lagos, UNS S30909 SS Sheets Port Harcourt, , SUS 309H Sheets and Plates Supplier in Abuja, 309H SS Perforated Sheets Exporter in Ibadan, DIN 1.4833 SS Perforated Sheets Price List in Nigeria, SS 309H Sheets Distributor in Port Harcourt, ASME SA 240 Stainless Steel 309H Sheets Supplier in Lagos, 309H SS Sheet and Plate Distributor in Nigeria, Stainless Steel 309H Shim Sheets Sizes in mm

Are Custom Sizes Available for Stainless Steel 309H Sheet and Plates?

Yes, we offer custom sizes for Stainless Steel 309H Sheet and Plates to meet specific project needs. Our team at Victor Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.

Customer Support

Largest Inventory

On Time Delivery

Quality Assurance

Competitive Pricing

Application Industry of Stainless Steel 309H Sheet and Plates

You’ll find Stainless Steel 309H Sheets and Plates in a variety of applications, including furnace parts, heat exchangers, boilers, kilns, and chemical processing equipment, where high-temperature strength and oxidation resistance are essential. Their ability to maintain structural integrity at temperatures soaring up to 1100°C makes them perfect for thermal processing, refinery, and incineration systems. The material’s strength also makes it a go-to choice for power plants, gas turbine components, and exhaust systems. Plus, SS 309H is favored in architectural and industrial fabrication due to its durability, corrosion resistance, and reliable performance across various applications.
