Stainless Steel 310H Sheet and Plates

Victor Sheets and Plates is a reputable manufacturer and supplier of Stainless Steel 310H Sheets and Plates based in Abuja, Nigeria. They pride themselves on delivering top-notch stainless steel products that perform exceptionally well in high-temperature and corrosive environments. Stainless Steel 310H is a high-carbon variant of SS 310, known for its enhanced creep strength and outstanding performance at elevated temperatures. At Victor Sheets and Plates, precision manufacturing, consistent quality, and adherence to international standards are top priorities. They cater to various industries, including petrochemical, power generation, furnace equipment, and heat treatment, providing durable, heat-resistant, and corrosion-resistant sheets and plates that are perfect for demanding industrial applications.

310H SS HR Plates

310H Stainless Steel Sheet

SS 310H Cold Rolled Sheets

ASTM A240 Stainless Steel 310H Sheets Dealer in Lagos, SS 310H Plates Supplier in Lagos, Stainless Steel S31009 Sheets and Plates in Port Harcourt, Stainless Steel Sheets and Plates Size Chart, 310H SS Sheets and Plates Price in Kano, ASME SA240 SS 310H Plates Supplier in Nigeria, 310H Stainless Steel Sheets in Ibadan, Stainless Steel 310H Sheet and Plate Supplier in Nigeria

The Stainless Steel 310H Sheets and Plates are made up of 24–26% chromium and 19–22% nickel, with a carbon content of up to 0.10%. This composition boosts high-temperature strength and creep resistance. Additionally, the alloy includes trace amounts of manganese, silicon, and phosphorus, which enhance oxidation resistance and structural stability. SS 310H boasts a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of 40%, with a density of 8.0 g/cm³ and a melting range between 1400–1450°C. These characteristics make it an excellent choice for prolonged exposure to high heat and thermal cycling conditions.

Stainless Steel 310H Sheet and Plates Specification

Specifications	ASTM A240 / ASME SA240
Width	1000mm / 1219mm /1250mm / 1500mm / 2000mm
Length	2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm
Thickness	0.1mm to 12 mm Thk
Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form	Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.

SS 310H Sheets and Plates Chemical Composition

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
310H	min.	0.04	–	–	–	–	24.0	–	19.0	–
310H	max.	0.10	2.0	1.00	0.045	0.03	26.0	–	21.0	–

SS 310H Sheets and Plates Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
310H	515	205	40	95	217

Equivalent Grades of A240 Stainless Steel 310H Sheets and Plates

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
		BS	En	No	Name
310H	S31009	–	–	–	–	–	–

310H Stainless Steel Hot Rolled Sheets Price in Kano, Stainless Steel 310H Shim Sheets Weight Chart, SS 310H Perforated Sheets Supplier in Nigeria, Stockist of SUS 310H Sheets and Plates in Ibadan, 310H SS Cold Rolled Sheets Supplier in Nigeria, 310H SS Cold Drawn Plates Price List in Abuja, SS 310H Chequered Plates Supplier in Ibadan, Stainless Steel 310H Chequered Plates Exporter in Lagos, Stainless Steel Plates Exporter in Nigeria, Stainless Steel Sheet 310H 2b Finish Exporter in Port Harcourt

Dimensions Standard of 310H Stainless Steel Sheets and Plates

Material	Size	Thickness
PLATES & SHEETS	1000 mm x 2000 mm	0.1mm To 100 mm Thickness
	1220 mm x 2440 mm (4′ x 8′)
	1250 mm x 2500 mm
	1500 mm x 3000 mm
	2000 mm x 4000 mm
	2000 mm x 2000 mm

SS 310H Sheets and Plate Standard Size Chart

2000MM X 1000MM X 3MM	2000MM X 1000MM X 6MM
2500MM X 1250MM X 4MM	2500MM X 1250MM X 8MM
3000MM X 1500MM X 3MM	3000MM X 1500MM X 6MM
3000MM X 1500MM X 4MM	3000MM X 1500MM X 8MM
2000MM X 1000MM X 5MM	2500MM X 1250MM X 10MM
2500MM X 1250MM X 3MM	2500MM X 1250MM X 6MM
4000MM X 2000MM X 3MM	4000MM X 2000MM X 6MM
2500MM X 1250MM X 5MM	3000MM X 1500MM X 10MM
2000MM X 1000MM X 4MM	2000MM X 1000MM X 8MM
4000MM X 2000MM X 4MM	2000MM X 2000MM X 10MM
3000MM X 1500MM X 5MM

If You Are Looking To Buy High Quality Piping Products ?

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Largest Stainless Steel 310H Sheet and Plates Manufacturer and Exporter in Abuja, Nigeria

Victor Sheets and Plates based in Abuja, Nigeria, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.

UNS S31009 Stainless Steel Sheets Distributor in Nigeria, SS 310H Plates Supplier in Abuja, Stainless Steel 310H Sheets Weight Chart, 310H Stainless Steel Hot Rolled Sheets Exporter in Ibadan, Stainless Steel 310H Shim Sheets Manufacturer in Lagos, SS 310H Chequered Plates Price List in Nigeria, 310H Stainless Steel Sheets Sizes in mm, Stainless Steel Sheet 310H 2b Finish Distributor in Port Harcourt, Stainless Steel 310H Sheets and Plates Exporter in Kano

Stainless steel 310H sheets and plates offer several key benefits. They provide excellent resistance to oxidation and corrosion, especially at high temperatures, making them ideal for harsh environments. With excellent strength and durability, 310H is well suited for applications between thermal cycling and high temperatures, such as furnaces, heat exchangers and boilers Its high carbon content increases its creep strength and stress breakdown properties, and provides it works for a long time. In addition, it maintains excellent weldability and formability, providing versatility for various engineering and fabrication applications.

Types of Stainless Steel 310H Sheet and Plates

BA Finish Stainless Steel 310H Plates in Lagos, UNS S31009 SS Sheets Port Harcourt, , SUS 310H Sheets and Plates Supplier in Abuja, 310H SS Perforated Sheets Exporter in Ibadan, SS Perforated Sheets Price List in Nigeria, SS 310H Sheets Distributor in Port Harcourt, ASME SA 240 Stainless Steel 310H Sheets Supplier in Lagos, 310H SS Sheet and Plate Distributor in Nigeria, Stainless Steel 310H Shim Sheets Sizes in mm

Are Custom Sizes Available for Stainless Steel 310H Sheet and Plates?

Yes, we offer custom sizes for Stainless Steel 310H Sheet and Plates to meet specific project needs. Our team at Victor Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.

Customer Support

Largest Inventory

On Time Delivery

Quality Assurance

Competitive Pricing

Application Industry of Stainless Steel 310H Sheet and Plates

Stainless Steel 310H Sheets and Plates find extensive use in high-temperature service applications, such as boiler baffles, heat exchangers, furnace components, kilns, combustion chambers, and equipment for petrochemical processing. Their remarkable ability to resist oxidation and scaling up to 1100°C makes them ideal for thermal processing and power generation facilities. They are also employed in refineries, incinerators, and flue gas systems, where durability and structural integrity under heat are essential. Furthermore, SS 310H is a popular choice for industrial ovens, pressure vessels, and architectural structures, ensuring long-lasting performance and excellent reliability.
