Victor Sheets and Plates is a trusted manufacturer and supplier of Stainless Steel 316H Sheets and Plates based in Abuja, Nigeria. They focus on delivering top-notch stainless steel materials designed for outstanding performance in high-temperature and corrosive settings. Stainless Steel 316H, being the high-carbon variant of 316, boasts improved strength, excellent creep resistance, and remarkable durability even at elevated temperatures. At Victor Sheets and Plates, precision manufacturing, exceptional surface finishes, and adherence to international standards are top priorities. They cater to various industries, including chemical processing, oil and gas, power generation, and marine engineering, providing reliable and efficient stainless steel solutions for critical applications.
Stainless Steel 316H Sheets and Plates mainly consist of 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, with a carbon content of up to 0.10% that enhances high-temperature strength. The alloy also includes manganese, silicon, and nitrogen to boost corrosion and oxidation resistance. SS 316H has a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of 40%, with a density of 8.0 g/cm³ and a melting range of 1370–1400°C. These characteristics make it perfect for challenging thermal and corrosive environments.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 316H | 1.4401 | S31609 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 316H Sheet and Plates offers several key benefits, especially in high-temperature environments. Its high carbon content also increases creep resistance, making it ideal for structural application in the chemical, petrochemical and marine industries. The material boasts excellent corrosion resistance, especially against chloride, pitting and crevice corrosion. It also performs well in extreme temperatures, maintaining its integrity in high temperature conditions. In addition, stainless steel 316H is durable, easy to manufacture, and highly resistant to oxidation, providing long service life with minimal maintenance These properties make it ideal for environmental production difficult to destroy.
Stainless Steel 316H Sheets and Plates find extensive use in heat exchangers, pressure vessels, boilers, condensers, and chemical processing equipment, thanks to their excellent resistance to corrosion, oxidation, and high-temperature scaling. Their superior creep and tensile strength make them ideal for power plants, refineries, and petrochemical industries, where prolonged exposure to high temperatures is the norm. They are also employed in marine, pharmaceutical, and food processing sectors for equipment that demands hygiene, strength, and reliability. Furthermore, SS 316H is a popular choice for industrial piping, architectural cladding, and welded structures, ensuring durability and performance in various applications.
