Victor Sheets and Plates, a reputable manufacturer and supplier located in Abuja, Nigeria, specializes in high-quality Stainless Steel 316Ti Sheets and Plates. These products are celebrated for their outstanding corrosion resistance, durability, and stability even at high temperatures. Thanks to the titanium alloying, this grade effectively prevents carbide precipitation during welding, ensuring top-notch performance in both chloride and acidic environments. Victor is committed to delivering 316Ti sheets and plates that adhere to international quality standards, boasting precise dimensions, a flawless finish, and impressive mechanical strength. These sheets and plates are perfect for applications in chemical processing, heat exchangers, marine equipment, and the pharmaceutical industry, guaranteeing long-lasting reliability in tough conditions.
Victor Sheets and Plates, a reputable manufacturer and supplier located in Abuja, Nigeria, specializes in high-quality Stainless Steel 316Ti Sheets and Plates. These products are celebrated for their outstanding corrosion resistance, durability, and stability even at high temperatures. Thanks to the titanium alloying, this grade effectively prevents carbide precipitation during welding, ensuring top-notch performance in both chloride and acidic environments. Victor is committed to delivering 316Ti sheets and plates that adhere to international quality standards, boasting precise dimensions, a flawless finish, and impressive mechanical strength. These sheets and plates are perfect for applications in chemical processing, heat exchangers, marine equipment, and the pharmaceutical industry, guaranteeing long-lasting reliability in tough conditions.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316Ti | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 316Ti sheets and plates offer exceptional advantages, including resistance to pitting, crack corrosion and excellent intergranular corrosion even at elevated temperatures The addition of titanium ensures stability against carbide precipitation, making it more difficult in rough environments. These sheets are strong, have excellent high-temperature strength and mechanical performance, making them ideal for complex applications. They resist oxidation and scaling, providing durability in marine, chemical and industrial applications. In addition, they are easy to manufacture, weld and maintain, providing cost effective and reliable for structural and process equipment applications.
Stainless Steel 316Ti Sheets and Plates are widely utilized in the chemical and petrochemical industries, as well as in marine and offshore settings where corrosion and heat resistance are essential. They’re perfect for applications like heat exchangers, evaporators, pressure vessels, pharmaceutical equipment, and exhaust manifolds. Additionally, you’ll find them in food processing, pulp and paper sectors, and architectural designs that demand durability and easy maintenance. The titanium stabilization helps maintain integrity during welding and high-temperature operations, effectively preventing sensitization. Victor’s 316Ti Sheets and Plates offer outstanding mechanical strength, corrosion resistance, and longevity, making them a dependable option for various industrial and engineering needs.
