Victor Sheets and Plates, a reputable manufacturer and supplier based in Abuja, Nigeria, specializes in high-quality Stainless Steel 410 Sheets and Plates. These products are known for their impressive mechanical strength, hardness, and decent corrosion resistance. As a martensitic stainless steel grade, 410 stands out for its exceptional wear resistance and can be heat-treated to boost its hardness and durability. At Victor Sheets and Plates, precision engineering and strict adherence to global quality standards are paramount, ensuring that their products perform reliably even in the toughest environments. These sheets and plates find extensive use in applications that require high strength, such as mechanical parts, pump shafts, and turbine components.
Stainless Steel 410 Sheets and Plates are made up of iron, 11.5–13.5% chromium, up to 0.15% carbon, along with trace amounts of manganese, silicon, and nickel. This martensitic alloy boasts a good tensile strength ranging from 450 to 750 MPa and can be hardened through heat treatment for superior wear resistance. It offers moderate corrosion resistance in mildly corrosive settings and excellent scaling resistance at elevated temperatures. Additionally, the material is known for its good machinability, moderate ductility, and high fatigue strength, making it a great choice for demanding mechanical applications.
| Standard | ASTM A240, ASME SA240 |
| Dimensions | ASTM, ASME, and API |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 4mm-100mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | Cr | Mn | Si | Ni | C | P | S | Fe |
| SS 410 | 11.50 – 13.50 | 0.0 – 1.50 | 0.0 – 1.00 | 0.0 – 0.75 | 0.08 – 0.15 | 0.0 – 0.04 | 0.0 – 0.02 | Balance |
| Tensile Strength Ksi (Mpa) | 0.2% Offset Yield Strength Ksi (Mpa) | Elongation, % in 2″ (51 mm) | Hardening Response HRC | HRB |
| 65 (450) – 74 (510) | 30 (205) – 42 (290) | 20 – 34 | 38-45 | 82-96 |
| Grade | WERKSTOFF NR. | UNS | AISI | BS | SIS | EN | JIS | AFNOR |
| SS 410 | 1.4006 | S41000 | 410 | 410S21 | 2302 | X12Cr13 | 410 | Z10C13/Z13C13 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 410 | 7750 | 200 | 9.9 | 11.4 | 11.6 | 24.9 | 28.7 | 460 | 570 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 410 sheets and plates offer a variety of benefits including excellent hardness and corrosion resistance, making them ideal for hard-wearing components such as cutlery, fasteners and valves especially in soft corrosive environments moderate corrosion resistance due to chromium content. Their high strength and durability enable them to be used in buildings and mechanical components. In addition, they can be heat treated, increasing the mechanical properties. Simple and affordable devices further enhance their appeal, making them a great choice for industries such as automotive, aerospace and construction.
Stainless Steel 410 Sheets and Plates are extensively utilized in industries that require high mechanical strength, wear resistance, and moderate corrosion protection. They are often found in the production of pump shafts, cutlery, turbine blades, valve components, and fasteners. In sectors like automotive and petrochemical, these materials are used for parts that face friction and heat. Moreover, they are applied in steam turbines, compressors, and various industrial machinery. Their capacity to be hardened through heat treatment makes them perfect for crafting tools and mechanical parts that need both toughness and dimensional stability in challenging operating conditions.
