Victor Sheets and Plates, a prominent manufacturer and supplier located in Abuja, Nigeria, is known for crafting top-notch Stainless Steel 409 Sheets and Plates. These products are celebrated for their remarkable resistance to corrosion, impressive durability, and ability to withstand high temperatures. Designed to excel in automotive, construction, and industrial settings, these sheets and plates are produced with precision using cutting-edge technology. They provide a cost-effective option for applications that face high heat and mild corrosive conditions. Victor Sheets and Plates is committed to delivering exceptional product quality, precise dimensions, and compliance with international standards for dependable performance.
Stainless Steel 409 Sheets and Plates mainly consist of iron and chromium (10.5–11.75%), along with small amounts of titanium and low carbon. This type of ferritic stainless steel offers solid oxidation and corrosion resistance, particularly in mildly corrosive and high-temperature situations. It boasts a tensile strength ranging from 380–550 MPa while maintaining ductility and weldability even after thermal cycling. The addition of titanium stabilizes the structure and helps prevent intergranular corrosion. Stainless Steel 409 also provides good formability and moderate strength, making it ideal for automotive and structural fabrication projects.
| Standards | ASTM A240 / ASME SA240 |
| Dimensions | ASTM, ASME, and API |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 0.01~200mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | the surface and finish of stainless steel 409 sheet: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mg | Ph | Si | Sl | Cr | Ti | Ni |
| 409 min 409 max | – 0.08 | – 1 | – 0.045 | – 1 | – 0.045 | 10.5 11.75 | 6xC – | – 0.5 |
| Density (lb / cu. in.) | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Modulus of Elasticity Tension |
| 0.278 | 7.86 | 0.11 | 29 |
| Grade | WERKSTOFF NR. | AISI | UNS | AFNOR | BS | GOST | JIS |
| SS 409 | 1.4512 | 409 | S40900 | Z3CT12 | 409 S 19 | SUH 409 | – |
|
Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Coefficient of Thermal Expansion (μm/m/°C) |
Thermal Conductivity (W/m.K) |
Specific Heat 0-100°C (J/kg.K) |
Electrical Resistivity (nΩ.m) |
|||
|
0-100°C |
0-315°C |
0-538°C |
at 100°C |
at 500°C |
|||||
|
409 |
7800 |
200 |
11.0 |
11.7 |
12.4 |
25.8 |
27.5 |
460 |
600 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 409 sheets and plates have many advantages, including excellent corrosion and oxidation resistance, and the high chromium content provides durability against scratches and scratches, especially in areas where fragile and hot. The material exhibits excellent weldability and formability, making it easy to manufacture for a variety of applications. Balancing strength and cost, stainless steel 409 is ideal for automotive exhaust systems, heat exchangers and furnace components. In addition, it resists thermal fatigue well and is very durable under extreme conditions.
Stainless Steel 409 Sheets and Plates are extensively utilized in the automotive sector for creating exhaust systems, catalytic converters, and mufflers, thanks to their outstanding heat and corrosion resistance. They also play a vital role in construction frameworks, heat exchangers, and industrial equipment that require moderate strength and durability. In the energy and food processing industries, these sheets and plates are essential for components that are exposed to heat and moisture. Furthermore, Stainless Steel 409 Sheets and Plates are commonly found in kitchen equipment, showcasing their versatility and reliability across various applications.
