Victor Sheets and Plates, a well-respected manufacturer and supplier located in Abuja, Nigeria, specializes in top-notch Stainless Steel 347 Sheets and Plates that are engineered for outstanding performance in high-temperature and corrosive settings. These sheets and plates are enhanced with niobium (columbium), which gives them remarkable resistance to intergranular corrosion and helps prevent carbide precipitation during welding. Renowned for their strength, durability, and resistance to oxidation, 347 stainless steel sheets are perfect for applications that require reliability in extreme conditions. Victor is committed to precision manufacturing and upholding international standards, making their 347 Sheets and Plates a reliable choice for the chemical, petrochemical, and aerospace sectors.
Stainless Steel 347 consists of about 17–19% chromium, 9–13% nickel, 0.45–1% niobium (columbium), with carbon levels reaching up to 0.08%, and manganese up to 2%. This alloy boasts a tensile strength ranging from 515–690 MPa, a yield strength of around 205 MPa, and an elongation of 40%, ensuring remarkable toughness and ductility. It can withstand oxidation up to 870°C (1600°F) and resists intergranular corrosion in the chromium carbide precipitation range. These characteristics make 347 stainless steel an excellent choice for high-temperature applications where welding and long-term stability are essential.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
| SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 20.00 | 10xC – 1.10 | 9.00 – 13.00 | 62.74 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 347 | 1.4550 | S34700 | SUS 347 | – | 08Ch18N12B | – | X6CrNiNb18-10 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 347 sheets and plates offer several advantages, including excellent resistance to intergranular corrosion, making them ideal for high-temperature applications The addition of niobium stabilizes the material and provides carbide precipitation a resistance is high, especially in the welded state. It provides excellent oxidation and scaling resistance at high temperatures, making it suitable for environmental applications such as chemical processing, power generation, aerospace industries etc. Stainless steel 347 with strength a outstanding, durable and corrosion resistance ensure long-term performance in extreme conditions, reduce maintenance costs and extend component life.
Stainless Steel 347 is made up of roughly 17–19% chromium, 9–13% nickel, and 0.45–1% niobium (also known as columbium), with carbon levels hitting up to 0.08% and manganese up to 2%. This alloy is known for its impressive tensile strength, which ranges from 515–690 MPa, a yield strength of about 205 MPa, and an elongation of 40%. These features contribute to its remarkable toughness and ductility. It can handle oxidation temperatures up to 870°C (1600°F) and is resistant to intergranular corrosion in the chromium carbide precipitation range. Because of these properties, 347 stainless steel is a fantastic option for high-temperature applications where welding and long-term stability are crucial.
