Stainless Steel 317L Sheets and Plates consist of roughly 18–20% chromium, 11–15% nickel, 3–4% molybdenum, and a low carbon content (≤0.03%). This distinctive composition boosts resistance to pitting, crevice corrosion, and intergranular attack. The alloy boasts a tensile strength of 515–690 MPa, a yield strength of about 205 MPa, and an elongation of up to 35%. It also maintains excellent formability, weldability, and oxidation resistance at higher temperatures. The low carbon content reduces carbide precipitation, making it ideal for welding and ensuring superior corrosion resistance in both chemical and marine environments.
Stainless Steel 317L Sheet and Plates is a low-carbon 317, providing superior corrosion resistance, especially in acidic environments. It includes about 18% chromium, 13% nickel and 3-4% molybdenum, which enhances resistance to pitting and cracks and corrosion. The lower carbon content reduces carbide precipitation, resulting in better weldability. The technical characteristics include a tensile strength of 485 MPa and a yield strength of 170 MPa. It exhibits excellent ductility and hardness, making it suitable for use in chemical, petrochemical and food processing industries where high corrosion resistance is required.
| 317L Sheets & Plates Specifications | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 317L Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| SS 317L Sheets & Plates Size Range | Cold rolled ASME SA240 Grade 317L Stainless Steel Sheet 0.5-6.4 mm Hot rolled ASME SA240 Grade 317L Stainless Steel Sheet 3.0–10.0 mm |
| 317L SS Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| SS 317L Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| SS 317L Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Stainless Steel 317L Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Stainless Steel 317L Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SA240 317L SS Strips EN 10088 SA -240-304 / 317L Strips |
| Finish of SS 317L Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
| 2000MM X 1000MM X 3MM | 2000MM X 1000MM X 6MM |
| 2500MM X 1250MM X 4MM | 2500MM X 1250MM X 8MM |
| 3000MM X 1500MM X 3MM | 3000MM X 1500MM X 6MM |
| 3000MM X 1500MM X 4MM | 3000MM X 1500MM X 8MM |
| 2000MM X 1000MM X 5MM | 2500MM X 1250MM X 10MM |
| 2500MM X 1250MM X 3MM | 2500MM X 1250MM X 6MM |
| 4000MM X 2000MM X 3MM | 4000MM X 2000MM X 6MM |
| 2500MM X 1250MM X 5MM | 3000MM X 1500MM X 10MM |
| 2000MM X 1000MM X 4MM | 2000MM X 1000MM X 8MM |
| 4000MM X 2000MM X 4MM | 2000MM X 2000MM X 10MM |
| 3000MM X 1500MM X 5MM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 317L sheets and plates offer many advantages, including exceptional corrosion resistance, especially in high chloride environments Their low carbon content increases weldability, prevents carbide precipitation and provides good welding strength after the. They exhibit excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, making them ideal for chemically complex marine environments 317L also maintains excellent tensile strength, rigidity and formability at temperature in a higher order. These properties make them ideal for use in industries such as the chemical industry, pharmaceutical manufacturing, marine and food processing, where durability and reliability are essential.
Stainless Steel 317L Sheets and Plates are a go-to choice in various industries like chemical processing, petrochemicals, food processing, pharmaceuticals, and marine applications. Why? Because they excel in tough environments filled with acids and chlorides. These materials are perfect for heat exchangers, evaporators, pressure vessels, condensers, and storage tanks that deal with corrosive solutions. You’ll also find them in pulp and paper plants, pollution control systems, and textile machinery, where resisting chemical attacks is absolutely essential. Victor’s 317L Sheets and Plates bring together strength, weldability, and corrosion resistance, guaranteeing long-lasting reliability and performance even in the most challenging industrial and environmental settings.
